Line Printer LP200 recorder
The Line Printer 200 continuous-line recorder with four line channels or three line channels and one printer channel is equipped for trend recording. The line channels are of Class 0.5 and the printer channel is of Class 1. The printer system in the recorder registers measured values and prints out alphanumeric texts. The measured values are registered at equidistant point intervals. Features:: - 1 to 4 measuring channels - Format 144 mm x 144 mm; installed depth 250 mm - Combined chart unit; roll or folded - Write width: 100mm - Channels galvanically separated and ungrounded - Universal input: DC, T/C, PT100 - Printer Channel (option) - RS-485 interface - Paper feed till 1200mm/h
